◈ Wide Measurement Range: Q3 /Q1 = 400; Q2 /Q1 =1.6, difficulties of small flow measurement are well solved.
◈ Low Starting Velocity: 5mm/s, much lower than traditional mechanical water meters, it can accurately measure even the minimum nighttime flow.
◈ High Reliability: The straight-pipe internal structure prevents blockage issues common with mechanical meters.
◈ Long-term Measurement Accuracy: No wear due to the absence of moving parts, ensuring consistent accuracy even beyond the typical 2-year inspection cycle.
◈ Direct Data Transmission: Instantaneous and accumulated flow data can be transmitted directly via RS-485, eliminating conversion errors.
◈ Anti-dismantle Design: All screws are hidden, and the joint is sealed with super glue and plastic lead seal to prevent tampering.
◈ IP68 Protection: Double O-ring seal and special grease ensure no water leakage even in long-term underwater use.
◈ Zero Straight Pipe: Proven accurate (Grade 2) even when installed between curves.
◈ Bidirectional Metering: Support bidirectional metering
◈ Strong Anti-interference: Comply with the E2 electromagnetic environment standard, the meter maintains measurement accuracy even when installed near a 250kW motor.
◈ Separate Installation (Optional): The sensor can be underground while the converter is installed in an accessible location.
◈ Compact Manometry (Optional): The pressure sensor can be fixed directly on the sensor of electromagnetic water meter without any opening on the pipe. The pressure data will be displayed on the LCD screen of water meter.
